TS 1500 G with hold-open
Guide rail TS 1500 G/F * with mechanical hold-open device and lever
- Quick installation due to clip-on sliding block
with mechanical hold-open device and lever
Application Areas
- Single leaf doors
- Installation on the hinge or opposite hinge side (only limited door leaf thicknesses)
- Right and left single-action doors
- To hold open non-fire protection doors
Technical data
| Guide rail TS 1500 G/F | |
| Length | 390 mm |
| Width | 30.5 mm |
| Height | 20.5 mm |
| opening restrictor upgradable | Yes |
| Hold-open device | Mechanical |
| Hold-open device can be overridden | Yes |
| Hold-open range | 80 ° - 130 ° |
Downloads
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
